LITE↯BLOX LB20XXMS (FIA killswitch & CAN-bus) Könnyű Akkumlátor Motorsport számára

features

• saves 15-22kg (33-48lbs) to standard starter battery
• plug’n’play replacement – fit for hardly any production car
• maintenance-free due to intelligent BMS-System (over-/undervoltage, over-/undertemperatur, overcurrent & short ciruit)
• full replacement for conventional circuit breaker systems with “solid-state” technology (CARTEK, ARMTECH) in a holistic solution, without additional motorsport harness
• wireless interface for wireless data monitoring via Smartphone App (can be deactivated)
• innovative & smart electronics for kill-switch via Smartphone App in two different programs:
  1.) I.K.O.S. – Intelligent Kill-Operation-Switch:
  effective disconnection of the LITE↯BLOX from the vehicle due to overload or via Smartphone (emergency or extended sitting periods), similar to the common FIA Kill-Off switch
  2.) A.V.A.T. – Active Vehicle Anti Theft:
  while all consumers are still being provided with energy, the LITE↯BLOX will instantly shut down at any theft attempt
• latest premium cell technology (A123 ANR26650M1B V3)
• rapid charging (optimal für Start-Stopp)
• marginally self-drain when not in use (sitting time >200days)
• fail safe due to innvative concept and premium materials
• FIA approved for Formula3 F3
• DMSB homologated (Lithium Ion battery RLB2016-27/17)
• tested to extense in professional motorsport along with the FIA

After many years of development and extensive field tests with selected partners in professional motorsport, we now offer our proven LITE↯BLOX product series as a special version for strictly racing applications.

The technology-leading LITE↯BLOX LB MotorSport accumulator series has been developed in close cooperation with a large semiconductor company to fit automotive standards and comes with an additional DEUTSCH Autosport connector including motorsport harness by DC electronics, enabling full integration into the vehicle’s CAN-bus system.

Using state-of-the-art semiconductor elements coupled with a powerful microprocessor, the LB20XXMS provides comprehensive & accurate telemetry recording (current, voltage, temperature) over the entire race distance, supporting fault diagnosis in the vehicle periphery – either via CAN bus or integrated wireless interface (smartphone / tablet).

Anwendung

• 4-8 cylinder engines (2500-4000ccm***)
• daily driven car use with restrictions (vehicle parking periods 2-4 weeks*)
• sportscar / tracktool / motorsport (race track circuit / 24h race / endurance / dragracing / formula F3 / NASCAR) / tuning / Car-Hifi / boats
• for the use in applications with intelligent battery management (IBS / IAC) –> battery programming mandatory!
• for the use in applications with regenerative brake system (“KERS”) use our model LB28XXMS only (for BMW F-Series M3 / M4, the LITE↯BLOX has to be programmed by our partner at Nurburgring)

technical data

• weight: 20XXg / 4,9lbs** (excl. pheriperals)
• dimensions: 149 x 123 x 100mm (l x b x h)
• voltage: 13,2V / 15,2V (nom / max)
• capacity: 12,5Ah / 35-50Ah (nom / Pb-eq)
• cranking current: 250A / 750A* (cont / peak @RT)
• temperature: -20 to +80°C
• lifespan: lifespan: 3-5x compared to the OEM battery*
• connection: OEM clamp onto the battery poles (DIN) or via ring terminal (M6)
• certificates: complies with directives 2001/95/EG, 2011/65/EU, 2006/66/EG, 2008/104/EU, UN38.3
• delivery scope: LITE↯BLOX + aluminium pole terminals + M6 mounting struts + pole caps + mounting material + motorsport harness (2x FIA kill-switch button / 1x CAN-bus adapter)

• * depending on usage, setup, peripheral, etc.

  ** since every LITE↯BLOX is built by hand, there might be marginal deviations in these values

  *** typical vehicles (recommendation only – please clarify with our customer service before purchase):

• Audi 80 100 A1 A2 A3 A4 TT TTS TTRS B5 B6
• Alfa Romeo 4c / Giulietta
• BMW E-Serie 1M M3 E30 E36 E90 E92 / F-Serie M2 M3 M4
• Caterham Super7 Seven 355 / 485
• Fiat 500 Abarth
• Ford Fiesta / Focus RS MK3 MK4 / Mustang
• Honda Civic / CRX / NSX / S2000
• Hyundai Genesis
• Lancia Delta
• Lexus IS (F)
• Lotus Elise Elan Exige Evora Europa
• Mazda MX5 3 5 RX7 RX8 MPS
• Mercedes W124 W201 E190 E300
• Mini Cooper R50 R51 R52 R53 R54 R55 R56 R58 S Works
• Mitsubishi Colt / Evo Evolution
• Nissan 350Z 370Z GT-R R32 R33 R34 R35 Skyline / Silvia
• Opel Kadett Ascona Corsa Astra OPC
• Porsche 911 993 964 986 987 996 997 718 981 Cayman Boxster
• Renault Clio MK1 2 3 4 / Megane MK1 2 4 4 RS Trophy
• Seat Ibiza Toledo Leon Cupra
• Skoda Fabia / Octavia RS
• Subaru WRX STI Impreza / BRZ
• Suzuki Swift / Ignis
• Toyota Celica / Supra / GT86
• VW (1-6 I-VI) Polo / Golf  R Clubsport S / Scirocco / Multivan T4 VR6 4motion / Käfer
• Westfield Super7
