LITE↯BLOX LB28XX lightweight battery for performance and motorsport

features

• saves 17-22kg (38-48lbs) to a standard starter battery
• plug’n’play replacement – fit for almost any production car
• wireless interface for wireless data monitoring via Smartphone App
• maintenance-free due to intelligent BMS-System (over-/undervoltage, over-/undertemperatur, overcurrent & short ciruit)
• innovative & smart electronics for kill-switch via Smartphone App in two different programs:
  1.) I.K.O.S. – Intelligent Kill-Operation-Switch:
  effective disconnection of the LITE↯BLOX from the vehicle due to overload or via Smartphone (emergency or extended sitting periods), similar to the common FIA kill-off switch
  2.) A.V.A.T. – Active Vehicle Anti Theft:
  while all consumers are still being provided with energy, the LITE↯BLOX will instantly shut down at any theft attempt
• latest premium cell technology (A123 ANR26650M1B V3)
• rapid charging (optimal für Start-Stopp)
• marginally self-drain when not in use (sitting time >250days)
• fail safe due to innvative concept and premium materials
• DMSB homologated (Lithium Ion battery RLB2016-27/17)
• tested in professional motorsport together with the FIA



  technical data

• weight: 28XXg / 6,2lbs** (excl. pole terminals)
• dimensions: 202 x 123 x 100mm (l x b x h)
• voltage: 13,2V / 15,2V (nom / max)
• capacity: 17,5Ah / 50-65Ah (nom / Pb-eq)
• cranking current: 350A / 1050A* (cont / peak @RT)
• temperature: -20 to +80°C
• lifespan: lifespan: 3-5x compared to the OEM battery*
• connection: OEM clamp onto the battery poles (DIN) or via ring terminals (M6)
• certificates:
• certificates: product complies with directives 2001/95/EG, 2011/65/EU, 2006/66/EG, 2008/104/EU
• delivery scope: LITE↯BLOX + aluminium pole terminals + pole caps + mounting material









• * depending on usage, setup, peripheral, etc.

  ** since every LITE↯BLOX is built by hand, there might be marginal deviations in these values

  *** typical vehicles (recommendation only – please clarify with our customer service before purchase):

  • AC Cobra
  • Audi TTS TTRS RS3 RS4 R8 S RS B6 B7
  • Alfa Romeo Giulietta
  • Bugatti Veyron
  • BMW E-Serie diesel / F-Serie M2 M3 M4 M5 M6
  • Chevrolet Camaro Corvette
  • Dodge Charger / Challenger / Viper
  • Ferrari 308 328 348 355 360 365 400 412 430 456 458 488 512 612 812 F12 F40 F50 Enzo
  • Ford Mustang / GT40 GT
  • Honda NSX
  • Jaguar F-Type
  • Koenigsegg CCR CCX Agera
  • Lamborghini Diabolo Gallardo Murcielago Huracan Aventador
  • Lexus IS (F) ES LS RC SC
  • Mercedes Benz E-Serie C-Serie CLA CLA45 AMG GTS GTR
  • Mosler MT900
  • Nissan GT-R R35 Skyline
  • Pagani Zonda Huayra
  • Porsche 911 9X1 991 991.2 GT2 GT3 RS / Carrera GT
  • Spyker C8 C12
  • Toyota Supra
  • VW (7 VII) Golf  7.5 R Clubsport S / Multivan T5
